MSL6000 series tape library user guide 33
Figure 14 Installing the library (two-drive model shown)
9. Remove the tape to open the doors for installation.
10. Remove and discard the pull-tabs used to block the latch mechanism.
NOTE: Do not close the doors. You must have access to the retaining screws to complete the
installation. (If necessary, see Chapter 4, ” Operation ” on page 49 for information on how to
manually open the library doors.)
11. With the doors open, secure the front panel to the rack enclosure using the retaining screws (see
Figure 15 ).
12. Close the doors. You can now cable the library.
