Configuration Examples
166
Configuration Examples
Figure 80
MSL6030/MSL6026, 2 hosts/2 drives
Figure 81
Single MSL6060/MSL6052, 4 hosts/4 drives
1
SCSI Terminator
2
0.5 m cable (to library controller card)
3
Host cable (Bus 1, to host system)
4
Host cable (Bus 0, to host system)
1
SCSI Terminator
2
0.5 m cable (to library controller card)
3
Host cable (Bus 1, to host system)
4
Host cable (Bus 3, to host system)
5
Host cable (Bus 2, to host system)
6
Host cable (Bus 0, to host system)
2
1
6
5
4
1
1
1
3
