6 REAR PANEL CONNECTIONS
Rear Panel Connections
O
P B
A
8 7 J
L K
N 4
D
C
F E
R
Q
5
6
I
G S
H
0 FM Antenna
1 AM Antenna
2 Phono Ground
3 Remote IR In
4 Remote IR Out
5 Phono Inputs
6 CD Inputs
7 Video 1 Audio/Video Play/In
8 Tape Monitor Play/In
9 Tape Monitor Record/Out A Video 1 Audio/Video Record/Out
B Video 2 Audio/Video Inputs
C Main In
D Video 3 Audio/Video Inputs
E Preamp Out
F Subwoofer Out
G Speaker 1 Terminals
H Speaker 2 Terminals
I Switched AC Outlet
J Power Cable K Video Monitor Outputs
L The Bridge Input (HK 3490 only)
M Update Cable Input
N Reset Switch
O Coaxial Digital Audio Input (HK 3490 only)
P Optical Digital Audio Input (HK 3490 only)
Q Subwoofer Trigger Outputs
R Subwoofer Link On/Off Switches
S Main On/Off Switch
