Operation
16 OPERATION
Using the Remote Control
It is convenient to think of the functions of the
remote control buttons in terms of “pages”,
where each source device (e.g. CD player) repre-
sents its own page of remote functions. The
result is that some of the keys will perform dif-
ferent functions depending upon which device
page has been selected prior to pressing the
key. Device pages are selected by pressing the
Source Selectors ç, which also changes the
input source selection on the HK 3490/HK 3390.
Source Selectors ç need not to be pressed
with each function, but only when you intend to
skip to another device to be controled.
The Video 1, Vide 2, Video 3, Tape Monitor/CDR
and CD device pages are factory-programmed to
operate compatible Harman Kardon products.
Video 1 controls Harman Kardon DMC players,
Video 2 and 3 controls Harman Kardon DVD
players, Tape Monitor controls Harman Kardon
CDR players/recorders, CD controls Harman
Kardon CD players. Please refer to the table
below for specific information on the default
functions of the affected keys for these devices.
REMOTE BUTTON FUNCTIONS
Harman Kardon DMC Harman Kardon DVD Harman Kardon CDR Harman Kardon CD HK 3490 only
Button Name Phone VID 1 VID 2 VID 3/VID Front TAPE MON CD AM FM The Bridge
Power ON System Power On System Power On System Power On System Power On System Power On System Power On System Power On System Power On System Power On
DMC Power On DVD Power On CDR Power On CD Power On
Power OFF System Power Off System Power Off System Power Off System Power Off System Power Off System Power Off System Power Off System Power Off System Power Off
DMC Power Off DVD Power Off CDR Power Off CD Power Off
Speak ers 1 Speaker 1 Speaker 1 Speaker 1 Speaker 1 Speaker 1 Speaker 1 Speaker 1 Speaker 1 Speaker 1
Speakers 2 Speaker 2 Speaker 2 Speaker 2 Speaker 2 Speaker 2 Speaker 2 Speaker 2 Speaker 2 Speaker 2
Phono Phono Phono Phono Phono Phono Phono Phono Phono Phono
CD CD CD CD CD CD CD CD CD CD
CD Power On CD Power On CD Power On CD Power On CD Power On CD Power On CD Power On CD Power On CD Power On
VID 1 VID 1 VID 1 VID 1 VID 1 VID 1 VID 1 VID 1 VID 1 VID 1
DMC Power On DMC Power On DMC Power On DMC Power On DMC Power On DMC Power On DMC Power On DMC Power On DMC Power On
VID 2 VID 2 VID 2 VID 2 VID 2 VID 2 VID 2 VID 2 VID 2 VID 2
DVD Power On DVD Power On DVD Power On DVD Power On DVD Power On DVD Power On DVD Power On DVD Power On DVD Power On
VID 3 VID 3/VID Front VID 3/VID Front VID 3/VID Front VID 3/VID Front VID 3/VID Front VID 3/VID Front VID 3/VID Front VID 3/VID Front VID 3/VID Front
FM FM FM FM FM FM FM FM FM FM
AM AM AM AM AM AM AM AM AM AM
Tape Mon. Tape Mon/CDR Tape Mon/CDR Tape Mon/CDR Tape Mon/CDR Tape Mon/CDR Tape Mon/CDR Tape Mon/CDR Tape Mon/CDR Tape Mon/CDR
CDR Power On CDR Power On CDR Power On CDR Power On CDR Power On CDR Power On CDR Power On CDR Power On CDR Power On
The Bridge (3490 only) The Bridge The Bridge The Bridge The Bridge The Bridge The Bridge The Bridge The Bridge The Bridge
FM Mode DMC Status DVD Status CDR Time FM Mode FM Mode
DSP Mode (3490 only) Surround Mode Surround Mode Surround Mode Surround Mode Surround Mode Surround Mode Surround Mode Surround Mode
Auto Preset DMC Subtitle DVD Subtitle DVD Subtitle CDR Finalize CD Program Check Auto Preset Auto Preset
1 1 1 1 1 CD 1 1 1
2 2 2 2 2 CD 2 2 2
3 3 3 3 3 CD 3 3 3
4 4 4 4 4 CD 4 4 4
5 5 5 5 5 CD 5 5 5
6 6 6 6 6 CD 6 6 6
7 7 7 7 7 CD 7 7 7
8 8 8 8 8 CD 8 8 8
9 9 9 9 9 CD 9 9 9
Direct DMC Info DVD Info DVD Chapter CDR Track Direct CD Source Frequency Direct Frequency Direct
0 0 0 0 0 CD 0 0 0
Clear DMC Clear DVD Clear DVD Clear CDR Clear CD Clear Clear Clear
Memory DMC Return DVD Play Mode DVD Return CDR Program CD Repeat Momory/Store Momory/Store
Cursor Up Cursor Up DMC Up (Navigation) DVD Up (Navigation) DVD OSD Up CDP Select CD Folder + Preset Tuning -> Preset Tuning -> Cursor Up
Menu Menu DMC Setup DVD Setup DVD Menu CD Time Menu
Cursor Left Cursor Left DMC Left (Navigation) DVD Left (Navigation) DVD OSD Left CDR Volume Down CD 10 - Cursor Left
Enter Enter DMC Enter DVD Enter DVD Enter CDR Random Play CD Play/Pause Enter
Cursor Right Cursor Right DMC Right (Nagivation) DVD Right (Nagivation) DVD OSD Right CDR Volume Up CD 10 + Cursor Right
Preset Scan DMC Title DVD Title DVD Intro Scan CDR Intro Scan CD Random Preset Scan Preset Scan
Cursor Down Cursor Down DMC Down (Navigation) DVD Down (Navigation) DVD OSD Down CDR Select CD Folder - Preset Tuning <- Preset Tuning <- Cursor Down
Disc Menu DMC disc Menu DVD disc Menu DVD disc Menu CD Info
Volum Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up Volume Up
Mute Audio Mute Audio Mute Audio Mute Audio Mute Audio Mute Audio Mute Audio Mute Audio Mute Audio Mute
Tuning Up >> DMC Zoom DVD Zoom DVD Page + CDR Disc Skip + ==== Tuning Up Tuning Up
Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down Volume Down
Tuning Down << DMC Audio DVD Audio DVD Page - CDR Disc Skip - ==== Tuning Down Tuning Down
Preset Down I<< Skip <- DMC Prev/Step DVD Prev/Step DVD Skip Back CDR Skip <- CD Previous Preset Tuning <- Preset Tuning <- Skip <-
Pause II Pause DMC Pause DVD Pause DVD Pause CDR Pause CD Play/Pause Pause
Preset Up >>I Skip -> DMC Next/Step DVD Next/Step DVD Skip Forward CDR Skip -> CD Next Preset Tuning -> Preset Tuning -> Skip ->
Search Backward << DMC Search/Slow <- DVD Search/Slow <- DVD Search <- CDR Search <- CD Search -
Play Play DMC Play DVD Play DVD Play CDR Play CD Play/Pause Play
Search Forward >> DMC Search/Slow -> DVD Search/Slow -> DVD Search -> CDR Search -> CD Search +
Rec DMC Record DVD Video Off CDR Record
Stop DMC Stop DVD Stop DVD Stop CDR Stop CD Stop
Dimmer Dimmer DMC Dimmer DVD Dimmer Dimmer Dimmer CD Display Dimmer Dimmer Dimmer
RDS Display DMC Video Mode DVD Video Resolution CD Program RDS Display
RDS PTY DMC Source CD Check RDS PTY
Sleep Sleep Timer Sleep Timer Sleep Timer Sleep Timer Sleep Timer Sleep Timer Sleep Timer Sleep Timer Sleep Timer
