Hitachi ULTRAVISION L32S504 - Manual (Page 33)

33
O
N
-S
C
R
E
E
N
D
IS
P
LA
Y
Audio
Select Audio to adjust the sound to your preference.
Video
Audio
Setup
Channels
Multimedia
Sound Mode Standard
Table Top
On
Stereo
48
0
32 Bass
Treble
Balance
CONEQ
CONEQ 3D Sound
Audio Source
Move Select SEL Return Exit EXIT
Sound Mode
This function has four sound modes that are preset according
to the type of program. Standard is for normal audio conditions,
Movie audio settings is for movies, News audio settings is for
News programs, and Custom mode is for adjusting audio levels
to your preference. The only mode that can be directly changed
by adjusting any audio setting to your desired conditions is the
Custom mode. The other modes are preset and any changes
made to these modes will be applied to Custom mode.
Audio Menu Settings Adjustment
1. Press the CURSOR PAD or to select menu item.
2. Press the CURSOR PAD or to adjust the function.
3. Press EXIT to quit the MENU, or select AUDIO to return to the
main menu.
If Treble is selected you are adjusting treble.
The additional menu items Bass and Balance can be
selected and adjusted in the same manner.
Bass
This function controls the low frequency audio to the speakers.
Treble
This function controls the high frequency audio to the speakers.
Balance
This function will control the left to right balance of the LCD TV
internal speakers and headphone jack.
CONEQ
Delivers clear crisp sound and high fidelity music playback.
Use CURSOR to select the preferred setting.
Table Top: Use this setting for improved sound quality with
table top stands.
Wall Mount: Select this setting for improved sound quality
when wall mounting.
Hearing Aid: This special mode is for users that want to
maintain clear sound after removing their conventional hearing
aid. Note that this feature emphasizes higher frequencies.
CONEQ 3D Sound
Produces a natural, three-dimensional sound image through the
TV’s sound system.
Audio Source
Multi-Channel Television Sound will allow you to select STEREO (a
stereo broadcast), MONO (monaural sound) used when receiving
a weak stereo broadcast or SECOND AUDIO PROG (SAP) which
may be a secondary language, weather report, etc. This setting is
only for analog programing.
NOTE
Preferred Language
Some programs transmit in other languages. This language
function will allow you to set between 3 language options (English,
Español, and Français) to your preference as the audio default
language.
Audio Language
Some programs transmit more than one DTV language option. Most
will have English as a default language. The language function will
allow you to select up to 6 language options (if available). Please
try all available options.
Digital Output
This function allows you to select between RAW and PCM.
This setting changes the format of the Digital Optical Output.
PCM- Select this feature if the TV is connected to an amplifier/receiver
with a PCM only decoder; it will provide two independent soundtrack
channels through the optical audio output jack (Digital Audio).
RAW- Select this feature to allow the original audio bit stream to
be passed through to the audio receiver.
Internal Speakers
This function is useful when using external speakers. Select ON if
using the internal speakers only. Select OFF if you prefer to use the
speakers from a separate stereo system.
Perfect Volume
This function will automatically adjust volume so each channel and
input has the same average volume level.
Reset
This function allows you to reset the Audio Menu Settings of the
present input source and return it to the Standard mode and default
settings.
Video
Audio
Setup
Channels
Multimedia
CONEQ 3D Sound On
On
PCM
Stereo
Off
Audio Source
Audio Language
Digital Output
Internal Speakers
Perfect Volume
Reset
Move Select SEL Return Exit EXIT
1. Use the CURSOR PAD , to highlight functions.
2. Press the SELECT button or the CURSOR PAD to select
Yes or No.
3. Press the SELECT button on the Yes option to execute the
reset of the Audio settings.
Depending upon the audio program being heard, you can
customize each audio input to your preference to increase audio
performance and pleasure.
If you run this Reset menu, only the present input source will reset
to its initial condition. For example, if the Reset menu has been
selected and done for HDMI 1 input source, only the HDMI 1
settings will return to its factory default.
