Heath Zenith SL-6157 User Manual

Chime extender

background image

Chime

Extender

Model SL-6157

Your chime extender includes (Style
of transmitter and chime may vary
from illustration):
• Plug-in doorbell chime
• Extension Transmitter
• Hardware pack

NOTE: You will need to purchase

four AAA batteries for the
transmitter.

To reduce the risk of electrical shock, this
equipment has a polarized plug (one
blade is wider than the other). This plug
will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit,
contact a qualified electrician to install the
proper outlet. Do not change the plug in
any way.

2.

Plug-in the doorbell chime.

1.

Set the chime volume on the back

of the plug-in chime, if desired.

Chime

Volume

Control

Access

Door

© 2003 DESA Specialty Products™

595-5345-06

Figure 1

Your Heath

®

/Zenith Chime Extender al-

lows you to add doorbell coverage to any
room in your house without the need to
run additional wires. The Chime Extender
"listens" for your existing doorbell to ring,
then transmits a radio frequency signal
to the plug-in chme unit in another part
of the house.
