Hustler Turf Z XR7 - Manual (Page 41)

106567 4/07 5-15
Instrument Panel Assembly
NOTES:
1. Part of 799320 (Common Wire Harness)
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 776476 776476 1 PTO SWITCH
2 785808 785808 1 IGNITION KEY SET
3 045898 045898 1 KEY SWITCH
4 785030 785030 1 Z CHOKE CABLE (KAWASAKI)
786657 786657 1 Z CHOKE CABLE (HONDA & KOHLER)
5 712257 712257 1 RED INDICATOR LIGHT
6 000430 000430 2 TIE STRAP
7 704932 704932 4 FW .219 X .500 X .048 ZN
8 714998 714998 2 MS #10-24 X .625 HX ZN
9 059832 059832 2 NT #10-24 HX NL ZN
10 769166 769166 1 HOUR METER
11 778365 778365 1 THROTTLE/CHOKE CABLE
12 055947 055947 3 CS .250-20 X .500 HX G5 ZN
13 768515 768515 3 FW .281 X .625 X .051 /.080 HD ZN/YL
14 106633 106633 1 INSTRUMENT PANEL
026237 N/A 6 RELAY (NOT SHOWN)
762195 N/A 1 DELAY MODULE (NOT SHOWN)
