Hustler Turf Z XR7 User Manual
Page 101
10-23
106567 4/07
FIG. 17
FIG. 18
FIG. 16
Resharpening pat-
tern
Do not sharpen to original pattern (below).
It is easier to get a straight cutting edge following the
resharpening pattern shown above.
Original edge
Warped Blade (Replace)
Straight Blade (Replace)
Comparison of Warped and Straight Blades
Cutting plane
Cutting edge
Cutting edge
Twisted Blade Edge
(replace)
Straight Blade Edge
End view of blades, comparing
twisted and straightened blades
Cutting Plane
