Hustler Turf Z XR7 - Manual (Page 19)

1065674/07 4-5
Deck Lift Assembly
NOTES:
1. Apply grease to zerks (see owner’s manual).
2. Verify pin diameter prior to ordering replacement part. For mowers with
3/8" diameter pins, order 348284; for mowers with 1/2" pins, order
600437. Item 3 includes 600437 (1/2" pin).
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 348318 348318 1 STOP HANDLE
2 600437 600437 1 DECK HEIGHT 1/2" PIN W/A
348284 N/A 1 HEIGHT ADJUSTMENT STOP 3/8"
3 783001 783001 1 DECK LIFT INDICATOR SUBASSEMBLY
4 704643 704643 8 NT .437-14 HX FLG ZN
5 781294 781294 7 CLIP E, 1.00 X .625 X .050
6 782995 782995 2 DECK LIFT SPRING SUBASSEMBLY
7 781229 781229 1 CE .750 X 2.25 X 1.75 HEADLESS
8 055749 055749 3 CS .437-14 X 1.750 HX G5 ZN
9 348391 018846 4 DECK LIFT CHAIN
10 015495 015495 4 STRAIGHT GREASE FITTING
11 034272 034272 1 NT .312-18 HX G5 ZN
12 756270 756270 1 CS .312-18 X 1.50 FUL THR GR5 ZN
13 348458 348458 1 DECK LEVELER YOKE
14 781831 781831 1 CS .437-14 X 1.750 FUL THD G5 ZN
2
{
