Fan/heat sink assembly
Description Spare part number
Fan/heat sink assembly (includes replacement thermal material) 506960-001
Before removing the fan/heat sink assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 32 ).
5. Remove the following components:
a. Optical drive (see Optical drive on page 35 )
b. Hard drive (see Hard drive on page 38 )
c. Keyboard and switch cover (see Keyboard and switch cover on page 40 )
d. Display assembly (see Display assembly on page 43 )
e. Top cover (see Top cover on page 49 )
f. System board (see System board on page 52 )
Remove the fan/heat sink assembly:
1. Turn the system board upside down, with the battery connector toward you.
2. Disconnect the fan cable (1) from the system board.
3. Loosen the three Phillips PM2.0×8.0 captive screws (2) that secure the fan/heat sink assembly to
the system board.
NOTE: Due to the adhesive quality of the thermal material located between the heat sink and
system board components, it may be necessary to move the heat sink from side to side to detach
the assembly.
58 Chapter 4 Removal and replacement procedures
