Hand Held Products 4410 User Manual
Page 163
7 - 31
OCR
*Default All OCR Settings*
OCRDFT.
*All OCR Off
OCRENA0.
OCR-A On
OCRENA1.
OCR-B On
OCRENA2.
U.S. Currency On
OCRENA3.
Enter OCR Template
OCRTMP.
Enter User-Defined Variable
“g”
OCRGPG.
Enter User-Defined Variable
“h”
OCRGPH.
OCR Modulo 10 Check
Character
OCRCHK”0123456789”.
OCR Modulo 36 Check
Character
OCRCHK”0123456789A
BCDEFGHIJKLM
NOPQRSTUVWXYZ”.
*Direction – left-to-right
ORCDIR0.
Direction – top-to-bottom
ORCDIR1.
Direction – right-to-left
ORCDIR2.
Direction – bottom-to-top
ORCDIR3.
Save OCR Template
MNUSAV.
Discard OCR Template
MNUABT.
1. XX = decimal value. Trigger on is defaulted to 18 and trigger off is defaulted to 20.
2. See the SDK User’s Guide for the commands needed to utilize Hardware Triggering.
3. VeriCode settings are not available in the standard Imager. An Imager with VeriCode
setting capability can be special ordered from the factory.
Selection
Setting
* Indicates Default Setting
Serial Command
