6
2. KM-650MWH (water-cooled)
Note: We reserve the right to make changes in specifications and design without prior
notice.
SPECIFICATION NO. 06A020
ISSUED: 10/10/2006
ITEM: HOSHIZAKI MODULAR CRESCENT CUBER
MODEL: KM-650MWH
AC SUPPLY VOLTAGE
208-230/60/1 (3 wire with neutral for 115V)
AMPERAGE 5.3 A ( 5 Min. Freeze AT 104°F / WT 80°F)
MINIMUM CIRCUIT AMPACITY 15 A
MAXIMUM FUSE SIZE 15 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day ( kg/day ) 70 *680 (308) 675 (306) 626 (284)
Reference without *marks 80 676 (307) 668 (303) 595 (270)
90 675 (306) *662 (300) 598 (271)
100 651 (295) 647 (294) 540 (245)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 14.8 lbs. (6.7 kg) 720 pcs.
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 1050(3.8) 1020(3.6)
WATER gal./24HR (gal./100 lbs.) 149(22.5) 254(37.4)
WATER COOLED CONDENSER 741(112) 408(60)
gal./24HR (gal./100 lbs.)
EXTERIOR DIMENSIONS (WxDxH) 22" x 27-3/8" x 37-7/16" (560 x 695 x 950 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 169 lbs. (77 kg), Shipping 200 lbs. (91 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT Condenser Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT Condenser Outlet 3/8" FPT
3/8" OD Tube
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled. Overflow Pipe
COOLING WATER CONTROL Pressure Regulator
BIN CONTROL SYSTEM Thermostat
COMPRESSOR Hermetic, Model RS55C2E-CAV
CONDENSER Water-cooled, Tube in tube type
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
REFRIGERANT CHARGE R-404A, 1 lb. 5.7 oz. (615g)
DESIGN PRESSURE High 427PSIG, Low 230PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out ( Internal )
COMPRESSOR PROTECTION Auto-reset Overload Protector ( Internal )
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES -SUPPLIED N/A
-REQUIRED Ice Storage Bin
OPERATING CONDITIONS VOLTAGE RANGE 187 - 253 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113 PSIG
DRAWING NO. (DIMENSION) 3A1898
We reserve the right to make changes in specifications and design without prior notice.
ENG.F-011.1.0205
