Form No. EBOOSTERM-0406 7
SPECIFICATIONS
kW Volts* Phase Amp Draw Breaker or Copper C o n d u i t
L1 L2 L3 Fuse Size Wire Size Size
36 208 1 173 173 - 225 4/0 1-1/2" (38 mm)
208 3 100 100 100 125 1 1-1/4" (32 mm)
240 1 150 150 - 200 3/0 1-1/2" (38 mm)
240 3 86.7 86.7 86.7 125 1 1-1/4" (32 mm)
380 3 54.7 54.7 54.7 70 4 1" (25 mm)
480 3 43.3 43.3 43.3 60 6 3/4" (19 mm)
600 3 34.7 34.7 34.7 50 8 1/2" (13 mm)
39 208 1 187.5 187.5 - 250 250 kcmil 2" (51 mm)
208 3 108 108 108 150 1/0 1-1/4" (32 mm)
240 1 163.5 163.5 - 225 4/0 2" (51 mm)
240 3 94 94 94 125 1 1-1/4" (32 mm)
380 3 59.3 59.3 59.3 90 3 1" (25 mm)
480 3 47 47 47 60 6 3/4" (19 mm)
600 3 37.6 37.6 37.6 50 8 1/2" (13 mm)
40 380 3 61.6 61.6 61.6 90 3 1" (25 mm)
40.5 208 3 112.5 112.5 112.5 150 1/0 1-1/4" (32 mm)
240 3 97.5 97.5 97.5 125 1 1-1/4" (32 mm)
480 3 48.8 48.8 48.8 70 4 1" (25 mm)
600 3 39 39 39 50 8 3/4" (19 mm)
45 208 3 125 125 125 175 2/0 1-1/2" (38 mm)
240 1 188 188 - 250 250 kcmil 2" (51 mm)
240 3 108 108 108 150 1/0 1-1/4" (32 mm)
380 3 68.6 68.6 68.6 90 3 1" (25 mm)
480 3 54 54 54 70 4 1" (25 mm)
600 3 43.4 43.4 43.4 60 6 3/4" (19 mm)
54 208 3 150 150 150 200 3/0 2" (51 mm)
240 3 130 130 130 175 2/0 1-1/2" (38 mm)
380 3 82.0 82.0 82.0 125 1 1-1/4" (32 mm)
480 3 65 65 65 90 3 1" (25 mm)
600 3 52 52 52 70 4 1" (25 mm)
57 208 3 158.4 158.4 158.4 225 4/0 2" (51 mm)
240 3 137.3 137.3 137.3 200 3/0 2" (51 mm)
380 3 86.7 86.7 86.7 125 1 1-1/4" (32 mm)
480 3 68.6 68.6 68.6 90 3 1" (25 mm)
600 3 54.9 54.9 54.9 70 4 1" (25 mm)
CIRCUIT BREAKER & FUSED DISCONNECT SWITCH SIZES - 36 to 57 kW
Wire size is based on THHN wire for branch circuit protection at .91 derate factor. Circuit breakers and fused
disconnects are to be mounted remote and wired by contractor. Sizes are based on the 2002 NEC table
310-16. Conduit size based on conductors plus ground wire sizing per Table C1 from Appendix C.
Only 6, 7 & 9 kW models can be field converted to single or three phase (open delta on 3 phase). Larger
branch circuit required than for balanced 3 phase of equal kW. Balanced 3 phase available, consult factory.
NOTE: 250 kcmil maximum wire size for terminal block.
