Page 35: Compaq proliant dl360 generation 2 storage
0,1
2 x 1 Inch Wide Ultra2/Ultra3 SCSI Hot Pluggable Hard Drive Bays
A
1.44-MB Diskette Drive (fixed)
B
Low-Profile 24x IDE CD-ROM (ejectable)
Drive Support
Quantity
Supported
Position
Supported
Controller
Removable Media
1.44-MB Diskette Drive
Up to 1
A
Integrated
Low-profile 24x IDE CD-
ROM Drive
Up to 1
B
Integrated IDE
Slim Line DVD-Rom
Drive (8x/24x) Option Kit
(Servers)
Up to 1
B
Integrated IDE
Hard Drives
Ultra320 Hot Pluggable Drives
Quantity
Supported
Position
Supported
Controller
1-inch
Up to 4
0-1
146.8-GB 10,000 rpm
72.8-GB 10,000 rpm
36.4-GB 10,000 rpm
72.8-GB 15,000 rpm
36.4-GB 15,000 rpm
18.2-GB 15,000 rpm
Smart Array 5i Controller (integrated on system board)
NOTE: The ProLiant DL360 Generation 2 (G2) does not offer an
external SCSI port.
64-bit/66-MHz Single Channel Wide Ultra3 SCSI
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter
NOTE: All U320 Universal Hard Drives are backward compatible to U2 or U3 speeds. U320 drives require an optional
U320 Smart Array Controller or U320 SCSI HBA to support U320 transfer rates.
External Storage
Quantity
Supported
Position
Supported
Controller
StorageWorks
Enclosure 4300 Family
(supports Ultra2/Ultra3
drives)
Up to 8
External
Smart Array 532 Controller
Smart Array 5302/128 Controller
Smart Array 5304/256 Controller
64-bit/66-MHz Single Channel Wide Ultra3 SCSI
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter
MSA 1000
Please see the
MSA 1000
QuickSpecs
below to
determine
configuration
requirements
External
Please see the MSA 1000 QuickSpecs (URL below) for the
latest list of supported HBAs
QuickSpecs
Compaq ProLiant DL360 Generation 2
Storage
DA - 11049 Worldwide QuickSpecs — Version 35 — 9.30.2003
Page 35
