BEFORE
YOU
BEGIN
10
INTRODUCTION
IMPORT
ANT
PRECAUTIONS
ASSEMBL
Y
BEFORE
YOU
BEGIN
ELLIPTICAL OPERA
TION
LIMITED
W
ARRANTY
TROUBLESHOOTING
&
MAINTENANCE
CONDITIONING
GUIDELINES
BEFORE YOU
BEGIN
ASSEMBL
Y
11
INTRODUCTION
IMPORT
ANT
PRECAUTIONS
ELLIPTICAL OPERA
TION
CONDITIONING GUIDELINES
TROUBLESHOOTING &
MAINTENANCE
LIMITED WARRANTY
ASSEMBLY STEP
LEFT LOWER LINK ARM
PEDAL ARM
LEFT PEDAL ARM
LINK ARM AXLE
FLAT WASHER (G) BOLT (F)
FLAT WASHER (E)
SPACER (H)
A) Open HARDWARE BAG FOR STEP 4.
B) Align the LINK ARM AXLE on the LEFT LOWER LINK ARM with the LEEFT PEDAL ARM.
C) Slide the SPACER (H) through the LINK ARM AXLE and the PEDAL ARM until it can no longer rotate.
D) Insert 2 FLAT WASHERS (G) between the PEDAL ARM and the LINK ARM AXLE.
E) Secure the joint with a FLAT WASHER (E) and BOLT (F).
F) Repeat on the other side.
ASSEMBLY STEP
LOWER HANDLEBAR
LOWER LINK ARM
LOWER LINK ARM
SPACER (O)
TEFLON WASHER (I)
LOWER
HANDLEBAR
LOWER LINK ARM
SPACER (O) TEFLON WASHER (I)
INSIDE ELBOW COVER
OUTSIDE
ELBOW COVER
SCREWS (N)
BOLT (J)
NUT (L)
BOLT (F)
15 mm
Qty: 2
FLAT WASHER (G)
28.4 mm
Qty: 4 SPACER (H)
Qty: 2
FLAT WASHER (E)
35 mm
Qty: 2
HARDWARE BAG FOR STEP CONTENTS :
SCREW (N)
15 mm
Qty: 4 BOLT (J)
60 mm
Qty: 2
SPACER (O)
Qty: 2
TEFLON WASHER (I)
28 mm
Qty: 4
NUT (L)
8 mm
Qty: 2
HARDWARE BAG FOR STEP CONTENTS :
A) Open HARDWARE BAG FOR STEP 5.
B) Slide SPACER (O) into LOWER LINK ARM.
C) Place 2 TEFLON WASHERS (I) on both sides of SPACER (O). While
holding TEFLON WASHERS (I), slide LOWER LINK ARM into bottom end
of LOWER HANDLEBAR.
D) Insert 1 BOLT (J) into LOWER HANDLEBAR and secure using 1 NUT (L).
E) Repeat on other side.
F) Attach the INSIDE and OUTSIDE ELBOW COvERS to the right LOWER
LINK ARM using 2 SCREWS (N).
G) Repeat on other side.
LOWER HANDLEBAR
LOWER LINK ARM
LOWER LINK ARM
SPACER (O)
TEFLON WASHER (I)
LOWER
HANDLEBAR
LOWER LINK ARM
SPACER (O) TEFLON WASHER (I)
INSIDE ELBOW COVER
OUTSIDE
ELBOW COVER
SCREWS (N)
BOLT (J)
NUT (L)
LOWER HANDLEBAR
LOWER LINK ARM
LOWER LINK ARM
SPACER (O)
TEFLON WASHER (I)
LOWER
HANDLEBAR
LOWER LINK ARM
SPACER (O) TEFLON WASHER (I)
INSIDE ELBOW COVER
OUTSIDE
ELBOW COVER
SCREWS (N)
BOLT (J)
NUT (L)
STEP B
STEP C STEPS D-G
Confirm that the
LOWER HANDLEBAR
and the
LOWER LINK ARM
are marked R. The left
side is marked L.
