English – 13
PRESENTATION
Presentation
Congratulations on your choice of an excellent quality product
that will give you great pleasure for many years. This
operator’s manual describes Rider 15V2 and Rider 15V2
AWD.
The machines are equipped with a 15 horse power engine
from Kawasaki.
Rider 15V2 AWD is equipped with all wheel drive.
The power transmission from the engine is handled by a
hydrostatic gearbox, which allows variable variation of the
speed by using the pedals.
One pedal for driving forward and one for reverse.
Throttle control
The throttle control regulates the engine speed, and thereby
also the rotation speed of the blades.
To increase or reduce the engine speed the control is moved
forwards or backwards.
Avoid idling the engine for long periods, as there is a risk of
carbon build-up on the spark plugs.
Choke control
The choke lever is used for cold starting and to give the
engine a richer fuel mixture.
For cold starting the lever is moved backwards to its end
position.
Speed limiter
The speed of the machine is steplessly regulated with two
pedals. Pedal (1) is used to drive forwards, and pedal (2) to
drive backwards.
Parking brake
The parking brake is applied as follows:
1 Press down the parking brake pedal (1).
2 Press in the lock button (2) on the steering column.
3 Release the parking brake pedal while keeping the button
pressed in.
The parking brake lock disengages automatically when the
brake pedal is pressed.
Cutting unit
Rider 15V2 and 15V2 AWD can be equipped with two
different cutting units.
• Combi 1030mm/41”
• Combi 1120 mm/44”
!
WARNING! Make sure that branches do not
obstruct the pedals when mowing under
bushes. Otherwise there is a risk you may
lose control.
1
2
