12 – English
WHAT IS WHAT?
Location of the controls
4 5 6
10 12 13
7 3 2
14 11 9 8
1
1 Choke control
2 Throttle control
3 Ignition lock
4 Cutting height adjustment lever
5 Lifting lever for the cutting unit
6 Speed limiter for reversing
7 Speed limiter for driving forward
8 Parking brake
9 Lock button for parking brake
10 Seat adjustment.
11 Lever to disengage the driving front axle, 15V2 AWD
12 Fuel cap
13 Cover lock
14 Lever to disengage the drive Rider 15V2
Lever to disengage the driving rear axle, 15V2 AWD
