Additional Features

Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control

Network Interface

Integrated Realtek RTL8139/810x Fast Ethernet Network Controller

Hardware Highlights

PCI interfaces

Features

10-Mbps and 100-Mbps operation

Intel PRO/1000 PT PCIe Gigabit NIC

Hardware Highlights

PCI interfaces

Features

10-Mbps, 100-Mbps and 1000-Mbps operation

Wireless

Wireless A+G PCI Card (full height bracket)

Power Supply

ATX Power Supply – Passive PFC/non-PFC with a 115v/230v line switch
Passive Power Factor Correction (PFC) – with line switch set to 230V – No PFC in 115V line switch
position
90 to 140VAC, or 180 to 264VAC operating voltage range
100 to 127VAC, or 200 to 240VAC rated voltage range
50–60 Hz rated line frequency
47–63 Hz operating line frequency range
250 watt maximum rated power
80-mm power supply fan – variable speed for optimum acoustics
(2) PATA device power connectors
(4) SATA device power connectors

Power Conservation

Power Conservation
‘Energy Saver‘

‘Energy Saver‘

APM 1.2 support
Screen blanking
Hard drive 'Idle' mode
System Idle mode
~2 watt power consumption in ES mode – suspend to RAM (S3) (instantly available PC)
Processor/Cache memory power-down (S3)

QuickSpecs

HP Compaq dx2250 Microtower Business PC

System Details

DA - 12605 Canada — Version 18 — March 24, 2008

Page 9
