62 - English
7. GARDEN EXAMPLE - PROPOSED INSTALLATION
Area: 0.4 acre (1600 m 2 ). L-shaped garden
with the charging station placed in the narrow
area. There are two islands. No guide wire is
necessary.
Timer: Operating time of 8 hours per day.
Exit angles: 250° - 290°
Search method: Irregular and Follow
boundary wire in.
Delay: Guide1, 2 minutes, Guide2, 2 minutes
and boundary wire 11 minutes.
Corridor width: 19
Area: 0.85 acre (3500 m 2 ). U-shaped garden
with the charging station placed on one of the
large open areas. Guide wire recommended
through the passage.
Timer: Operating time of 10 hours per day.
Exit angles: 90° - 270°.
Follow loop out: Direction Guide 1, Distance
25 meters (80 ft) and Proportion 30 %.
Search method: Irregular and Follow guide
wire in.
Delay: Guide1, 2 minutes, Guide2, 2 minutes
and boundary wire 99 minutes. Automower
®
is never permitted to follow the boundary
wire.
Corridor width: Guide1 6
Area: 1.4 acre (5500 m 2 ). Rectangular
garden with the charging station placed by an
island. A large part of the boundary wire is
routed on a slope that is steeper than 10 %.
Guide wire recommended.
Timer: Operating time of 24 hours per day.
Exit angles: 90° - 270°.
Search method: Irregular and Follow guide
wire in.
Delay: Guide1, 2 minutes, Guide2, 2 minutes
and boundary wire 99 minutes. Automower
®
is never permitted to follow the boundary
wire.
Corridor width: 19
Proposals for installation and settings
16 ft
