HP IPAQ HX2750 - Manual (Page 7)

Bluetooth Bluetooth Bluetooth Bluetooth®
Specifications
Specifications Specifications Specifications 1 1 1 1
Technology Technology Technology Technology High-speed, low-power, short-range wireless communication with other Bluetooth devices
Bluetooth specification Bluetooth specification Bluetooth specification Bluetooth specification 1.2 compliant (2.4-GHz Industrial Scientific Medical Band)
System interface System interface System interface System interface High-speed UART processor interface
User Interface User Interface User Interface User Interface Bluetooth Manager
Device type Device type Device type Device type Class II device; up to 4 dBm transmit, typical 10 meter range
Power Power Power Power 3.3V 5% Peak current – typical TX current at approximately 30 mA
– typical RX current at approximately 50 mA
Receiver sensitivity Receiver sensitivity Receiver sensitivity Receiver sensitivity -83 dBm
Regulatory standards Regulatory standards Regulatory standards Regulatory standards R&TT#-EN 300 328 and EN 300 826, UL 1950, CB Safety Scheme inclusive of EN 60950
and IEC 950, FCC Part 15 subpart C, Canadian, CE
Profile Support Profile Support Profile Support Profile Support General Access Profile
Service Discovery Application Profile
Serial Port Profile
Generic Object Exchange Profile
File Transfer Profile
Dial-Up Networking Profile
LAN Access Profile
Object Push Profile
Personal Area Networking Profile
Basic Printing Profile
Hard Copy Replacement Profile (printing)
Headset Profile
Usage Models Usage Models Usage Models Usage Models Service Discovery Service Discovery Service Discovery Service Discovery
Determine what Bluetooth devices are within range and support authorization
File Transfer File Transfer File Transfer File Transfer
File and directory browsing and navigation on another Bluetooth device.
File copying
Object manipulation – including add, delete, create new folders etc.
Serial Port Serial Port Serial Port Serial Port
Synchronization between PDAs and PCs
Dial Up Networking Dial Up Networking Dial Up Networking Dial Up Networking
Wireless link to WAN thru Bluetooth enabled cell phone
1,3,4
Agnostic to WAN technology
Send/receive SMS messages
LAN Access LAN Access LAN Access LAN Access
Wireless link to Corporate LAN using Bluetooth and appropriate Bluetooth access point
1
Corporate email, network neighborhood, access to LAN applications, file transfer, ftp,
Internet browsing, etc, using TCP/IP
1
Access the Internet by connecting to your desktop or notebook over Bluetooth and using its
network connection
1
Generic Object Exchange and Object Push Generic Object Exchange and Object Push Generic Object Exchange and Object Push Generic Object Exchange and Object Push
Exchange business cards, tasks, documents, appointments and more
1
Personal Area Networking Personal Area Networking Personal Area Networking Personal Area Networking
Collaborate, chat, play games, exchange data
1
Adhoc peer to peer networking 1
Basic Printing and Hard Copy Replacement Profiles Basic Printing and Hard Copy Replacement Profiles Basic Printing and Hard Copy Replacement Profiles Basic Printing and Hard Copy Replacement Profiles
Print to any HP Bluetooth enabled printer without the need for cables or specific print
drivers
Certifications Certifications Certifications Certifications All necessary regulatory approvals for countries supported including:
Bluetooth logo (FCC (47 CFR) Part 15C, Section 15.247&15.249 ETS 300 328, ETS 301
489-1/17 Low Voltage Directive IEC950 UL and CE Mark
NOTE: NOTE: NOTE: NOTE:
1 A standard Wi-Fi infrastructure, other Bluetooth-enabled devices, separately purchased equipment, and a service contract
with a wireless airtime provider may be required for applicable wireless communication. Wireless Internet use requires a
separately purchased service contract. Check with wireless network service providers for availability and coverage in your
area. Not all web content available.
QuickSpecs
HP iPAQ hx2750 Pocket PC HP iPAQ hx2750 Pocket PC HP iPAQ hx2750 Pocket PC HP iPAQ hx2750 Pocket PC
Standard Features
DA - 12065 North America — Version 3 — December 23, 2004 Page 7
