915 series Express chipset 915 series Express chipset 915 series Express chipset 915 series Express chipset
DDR SYNCH DRAM NON-ECC MEMORY
DDR SYNCH DRAM NON-ECC MEMORY DDR SYNCH DRAM NON-ECC MEMORY DDR SYNCH DRAM NON-ECC MEMORY
It is not necessary to add memory in pairs. Memory upgrades are accomplished by adding single or multiple DIMMs of the same or
varied sizes. This chart does not represent all possible memory configurations. The Intel 915G/series Express chipsets support non-
ECC DDR PC2700 (333-MHz) and non-ECC DDR PC3200 (400-MHz) memory.
For best performance, add in pairs, add in same channel, and do not mix speeds. For dual-channel performance, the total amount
of memory in each channel should be equal. If speeds are mixed, speed will default to the slowest DIMM.
MAXIMUM MEMORY (ULTRA-SLIM DESKTOP)
MAXIMUM MEMORY (ULTRA-SLIM DESKTOP) MAXIMUM MEMORY (ULTRA-SLIM DESKTOP) MAXIMUM MEMORY (ULTRA-SLIM DESKTOP)
Supports up to 3-GB of DDR SYNCH DRAM. Not all memory configurations possible are represented below.
DIMM Size DIMM Size DIMM Size DIMM Size Slot Slot Slot Slot
Channel A Channel A Channel A Channel A Channel B Channel B Channel B Channel B
1 1 1 1 2 2 2 2 3 3 3 3
128-MB 128-MB
256-MB (dual channel) 128-MB 128-MB
512-MB 512-MB
512-MB (dual-channel) 256-MB 256-MB
1-GB 1-GB
1-GB (dual channel) 512-MB 512-MB
2-GB (dual-channel) 1-GB 1-GB
2-GB 512-MB 512-MB 1-GB
3-GB maximum 1-GB 1-GB 1-GB
915G Express chipset
915G Express chipset 915G Express chipset 915G Express chipset
DDR SYNCH DRAM NON-ECC MEMORY
DDR SYNCH DRAM NON-ECC MEMORY DDR SYNCH DRAM NON-ECC MEMORY DDR SYNCH DRAM NON-ECC MEMORY
It is not necessary to add memory in pairs. Memory upgrades are accomplished by adding single or multiple DIMMs of the same or
varied sizes. This chart does not represent all possible memory configurations. The Intel 915G Express chipset supports non-ECC
DDR PC2700 (333-MHz) and non-ECC DDR PC3200 (400-MHz) memory.
For best performance, add in pairs, add in same channel, and do not mix speeds. For dual-channel performance, the total amount
of memory in each channel should be equal. If speeds are mixed, speed will default to the slowest DIMM.
MAXIMUM MEMORY (SMALL FORM FACTOR AND CONVERTIBLE MINITOWER)
MAXIMUM MEMORY (SMALL FORM FACTOR AND CONVERTIBLE MINITOWER) MAXIMUM MEMORY (SMALL FORM FACTOR AND CONVERTIBLE MINITOWER) MAXIMUM MEMORY (SMALL FORM FACTOR AND CONVERTIBLE MINITOWER)
Supports up to 4-GB of DDR SYNCH DRAM. Above 3-GB, all memory may not be available due to system resource requirements.
Not all memory configurations possible are represented below.
QuickSpecs
HP Compaq Business Desktop dc7100 Series HP Compaq Business Desktop dc7100 Series HP Compaq Business Desktop dc7100 Series HP Compaq Business Desktop dc7100 Series
Memory
DA - 11948 North America — Version 33 — January 31, 2006 Page 15
