Installation – Husqvarna 2003-06 User Manual
Page 23
English-
24
INSTALLATION
3.
Place the cable ends in the connector:
• Open the connector.
• Place the wire in the connector grip.
4.
Press the connector together using a pair of pliers.
Press until you hear a click.
5.
Cut off any surplus boundary wire. Cut 1-2 cm
above respective connectors.
6.
Press the connector onto the metal pin on the
charging station.
3012-284
3012-264
3012-265
3012-267
IMPORTANT INFORMATION
The right hand connector should be connected
on the right hand metal pin on the charging sta-
tion and vice versa.
