English- 16
INSTALLATION
Plan the position of the charging station according to
the shape of your garden.
The Auto Mower can be set for one of three basic gar-
den shapes (see page 34).
The Auto Mower works differently depending on the
garden shape the mower has been set to.
The available garden shapes are: open, complex 1 and
complex 2.
The following pictures are examples of the different
garden shapes. The pictures are also good examples
of appropriate charging station placement.
• The open shape represents a lawn area with few
obstacles and no passages.
• Complex 1 is a large lawn area with an average
amount of obstacles and passages.
3012-290
3012-291
Example of the open garden shape. Lawn area 400 m 2 and 1100 m 2
2,5
3012-292
3012-293
Example of complex 1 garden shape. Lawn area 900 m 2 respective 1000 m 2
2,5
