Panel Control and Rear Terminals Control
6 LED -LCD television Owner’s Manual
Panel Control and Rear Terminals Control
- This is a simplified representation of front panel.
- Here shown may be somewhat different from your TV.
Panel Control
SOURCE
LE22T3W “TV/AV”
LED LCD
Rear Terminals Control
5
1
2
7 8 9
10
3
4
6
PC IN
DIGITAL OUT
(COAXIAL)
HDMI IN
1
COMPONENT In
Connect a component Video/Audio device to
these jacks
2
AV IN
Connect Video/Audio out from an Video/Audio
device to these jacks
3
PC IN
Connect the monitor output connector from a PC
to the jack
4
AV OUT Video/Audio output terminal
5
DC IN
Connect the monitor output connector from a DC
to the jack(not available for the L24K3 model)
6
Headphone
7
USB
Connect a USB flash drive to view PPEG2
videos,JPEG images or listen to MP3 songs.
8
DIGITAL
OUT(COAXIAL)
Digital/Coaxial output terminal
9 HDMI Connect a signal to HDMI
0 PC/DVI AUDIO Connect a PC/DVI Audio device to these jacks
