OM-244 013 Page 34
SECTION 8 ï PARTS LIST
8-1. Recommended Spare Parts
243 016-A
CAUTION
•
•
•
Turn off power before checking torch parts.
Check before each use and hourly during operation.
Torque electrode lightly w/small wrench (15 – 20 in. lbs.)
FAILURE TO REPLACE WORN TIP OR ELECTRODE
WILL DAMAGE TORCH AND VOID WARRANTY.
HP-70 CONSUMABLE KITS
243016-A
Retaining Cup
Tip Electrode
Swirl Ring O-Ring
770 654
770 655
Figure 8-1. Consumable Parts For HP-70
Description
Part
No.
Dia.
Mkgs.
Item
No.
Recommended Spare Parts
Quantity
244 122 TORCH, HP-70 16.4ft (5 m) hand held (replacement) 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
208 820 CLAMP, work 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
770 654 CONSUMABLE KIT, tip/electrode 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
770 655 CONSUMABLE KIT, cup/swirl ring/O-ring 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
227 877 FILTER, air element 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
232 257 CABLE, work 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
233 321 STAND-OFF GUIDE, HPï25/50/70 PLASMA TORCH 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
233 046 WRENCH, electrode 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
245 993 KIT, detect leads 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.
A complete Parts List is available on-line at www.MillerWelds.com
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and serial number required when ordering parts from your local distributor.
