OM-244 013 Page 19
SECTION 5 ï OPERATION
5-1. Controls
1 Output Control
Use control to set cutting output.
If 22-27 amperes of cutting output is used
with 120 VAC input power, and the overload
protection on the input power circuit fre-
quently opens, either reduce the cutting out-
put and/or the cut time or find more adequate power (see Section 4-1).
2 Power Light
3 Trouble Lights (See Section 6-4)
243 013-A
3
1
2
20
25
35
30
CUTS:
40
1/2” CLEAN CUT (STEEL)
7/ 8" SEVER CUT (STEEL)
3/8" STAINLESS
3/8" ALUMINUM
3/8" GALVANIZED
1/4" BRASS
V POWER
TEMP
ON
OFF
V
PRESSURE
CUP
3/16" COPPER
