HP ProLiant BL460c - Manual (Page 29)

HP ProLiant BL460c
Server Blade Dimensions Height 2.207 in (5.61 cm)
Depth 20.058 in (50.95c m)
Width 7.154 in (18.17 cm)
Weight Maximum 14.20 lb (6.44 kg)
Temperature Range * Operating 50°F to 95°F (10°C to 35°C)
Non-Operating -40°F to 140°F (-40°C to 60°C)
Storage -4°F to 140°F (-20°C to 60°C)
Maximum Wet Bulb
Temperature 86°F (-30°C)
Operating 10% to 90%
Relative Humidity ** Shipping 10% to 90%
Storage 10% to 95%
*NOTE: All temperature ratings shown are for sea level. An altitude derating of 1°C per 1.8°F per
1,000 ft (304.8 m) to 10,000 ft (3048 m) is applicable. No direct sunlight allowed. Upper operating
limit is 10,000 ft (3,048 m) or 70 Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or
30.3 KPa/4.4 psia.
**NOTE: Storage maximum humidity of 95% is based on a maximum temperature of 113°F
(45°C). Altitude maximum for storage corresponds to a pressure minimum of 70 KPa.
Smart Array E200i
Controller Disk Drive and
Enclosure Interface 3G SAS (Serial Attached SCSI)
1.5G SATA (Serial Advanced Technology Attachment)
SAS Connectors 2 internal (SFF8484) x4 wide port connectors
Cache Memory Speed DDR-1/266 MHz provides up to 4.2 GB/s maximum bandwidth.
Server Interface x4 2.5G PCIe provides 2GB/s maximum bandwidth.
SAS Speed x8 3G SAS provides 2.4GB/s maximum bandwidth.
Cache Memory 40-bit 64MB or 128MB cache: ECC protection, battery-backed, and
transportable
Logical Drives
Supported Up to 32 logical volumes
Maximum Logical Drive
Capacity 144GB (2 x 72GB)
Host Memory
Addressing 64-bit, supporting greater than 2GB server memory space
RAID Support RAID 5 (Distributed Data Guarding)
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
Upgradeable Firmware Upgradeable Firmware
QuickSpecs
HP ProLiant BL460c Server Blade
Technical Specifications
DA - 12518 Worldwide QuickSpecs — Version 2 — 6/14/2006 Page 29
