Operating System (choice) Microsoft Windows XP Professional (32-bit)

Microsoft Windows XP Professional x64 Edition
Red Hat Enterprise Linux Workstation 3 64-bit version Update 5. (Both 32- and 64-bit versions available
as aftermarket option.)
HP Installer Kit for Linux 1 (includes drivers for both 32-bit & 64-bit OS versions)
(Tested and supported on Microsoft Windows 2000 Professional SP4. See HP White Paper at:

http://www.hp.com/workstations/white_papers/docs/xw4300_win2k_whitepaper_sept2005.pdf

)

Form factor

Minitower

Color

Carbonite/Alloy metallic

Convertibility

Yes. 5.25" drives rotate for Minitower or Desktop orientation.

System Board Form Factor ATX (9.6 x 12 in)
Processor

Single Intel Pentium 4 processors with Hyper-Threading Technology or Pentium D processors

CPU Bus Speed
Supported

1066 and 800 MHz FSB

Standard L2 Cache

1 or 2 MB L2 cache, depending on specific processor

Chipset

Intel 955X North bridge/ICH7R South bridge

Memory Expansion Slots 4 DIMMs
Memory Type Supported DDR2 (ECC and non-ECC)
Memory Speed Supported DDR2 SDRAM PC2-4300 (533 MHz) ECC

DDR2 SDRAM PC2-5300 (667 MHz) ECC
DDR2 SDRAM PC2-4300 (533 MHz) non-ECC

Maximum Memory

8 GB (4 DIMM slots)

Network controller

Integrated Broadcom 5752 10/100/1000 for HP (PCI Express interface)

Audio

Integrated High Definition digital audio with stereo microphone

PCI slots

3 PCI slots (full-height, full-length)
1 PCI Express x8 slot (x4 functionality)
1 PCI Express x1 slot
1 PCI Express x16 graphics slot

AGP slot

None

Bays

Total Bays = 6

Internal Bays

Two 3.5 inch SATA Hard Drive

External Bays

Three 5.25 inch bays
One 3.5 inch bay for optional floppy drive

Parallel Port

1

Serial Port

1 standard, 2nd is optional

Front I/O

2 USB 2.0, IEEE-1394 (requires optional PCI card to function), headphone and microphone.

NOTE:

NOTE:

NOTE:

NOTE: Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux Hardware
Support Matrix (

http://www.hp.com/support/linux_hardware_matrix

) for details, and to the Linux User

Manual (

http://www.hp.com/support/linux_user_manual

) for tips on user-enablement of the IEEE 1394

Card.

Rear I/O

6 USB 2.0, 1 standard serial port, 1 optional serial port, parallel port, PS/2 keyboard, PS/2 mouse, RJ-
45, audio in, audio out, mic in (audio/mic ports can be made function autosensing and interchangeably
retaskable by downloading a driver)

USB Keyboard

Optional

USB Mouse

Optional

PS/2 Keyboard

1

PS/2 Mouse

1

QuickSpecs

HP xw4300 Workstation

HP xw4300 Workstation

HP xw4300 Workstation

HP xw4300 Workstation

Standard Features - Specs

DA - 12260 Worldwide — Version 14 — March 1, 2006

Page 9
