SpaceBall 5000 SpaceBall 5000 SpaceBall 5000 SpaceBall 5000 (USB) Physical characteristics Physical characteristics Physical characteristics Physical characteristics Dimensions Dimensions Dimensions Dimensions (H x W x D) 3.0 x 6.0 x 8.4 in (7.6 x 15.2 x 21.3 cm)
Ball Diameter Ball Diameter Ball Diameter Ball Diameter 2.2 in (5.6 cm)
Weight Weight Weight Weight 2.1 lb (9.94 kg)
Features Features Features Features Six degrees of freedom motion control through
the X, Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC applications
Environmental Environmental Environmental Environmental Operating temperature Operating temperature Operating temperature Operating temperature 50° to 104° F (10° to 40° C)
Non-operating Non-operating Non-operating Non-operating
temperature
temperature temperature temperature
43° to 140° F (6° to 60° C)
Operating humidity Operating humidity Operating humidity Operating humidity 8% to 80% (non-condensing at ambient)
Non-operating humidity Non-operating humidity Non-operating humidity Non-operating humidity 5% to 80% (non-condensing at ambient)
Mechanical Mechanical Mechanical Mechanical Buttons Buttons Buttons Buttons 12 programmable (unshifted)
Ball Force Range Ball Force Range Ball Force Range Ball Force Range 0.5 - 8.2N/1.8 - 29.5 oz
Ball Torque Range Ball Torque Range Ball Torque Range Ball Torque Range 0.085 – 0.33 oz-in. (6.91 Nmm)
Resolution Resolution Resolution Resolution 10 bits
Serial Specifications Serial Specifications Serial Specifications Serial Specifications Connector Connector Connector Connector USB 1.1 or greater
Cable Length Cable Length Cable Length Cable Length 12.8 ft. (3.9 m)
Data Rate Data Rate Data Rate Data Rate USB model – 16 msec
Flow Control Flow Control Flow Control Flow Control Xon/Xoff (on PS/2 model only)
Software Drivers Available Software Drivers Available Software Drivers Available Software Drivers Available USB model USB model USB model USB model Microsoft Windows XP Professional
System Requirements System Requirements System Requirements System Requirements Disk Space Disk Space Disk Space Disk Space 10 MB free disk space
Regulatory Approvals Regulatory Approvals Regulatory Approvals Regulatory Approvals UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN
50082, IEC 1000 4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick
HP SpaceMouse Plus USB HP SpaceMouse Plus USB HP SpaceMouse Plus USB HP SpaceMouse Plus USB Physical characteristics Physical characteristics Physical characteristics Physical characteristics Dimensions Dimensions Dimensions Dimensions (H x W x D) 7.4 x 4.72 x 1.73 in (18.8 x 12.0 x 4.4 cm)
Cap Diameter Cap Diameter Cap Diameter Cap Diameter 2 x 6.5 x 6.6 mm
Weight Weight Weight Weight 1.5 lb (0.68 kg)
Features Features Features Features Six degrees of freedom motion control through
the X, Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC applications
Environmental Environmental Environmental Environmental Operating temperature Operating temperature Operating temperature Operating temperature 41° to 140° F (5° to 60° C)
Non-operating Non-operating Non-operating Non-operating
temperature
temperature temperature temperature
-13° to 158° F (-25° to 70° C)
Operating humidity Operating humidity Operating humidity Operating humidity 10 to 98 % RH (non-condensing)
Non-operating humidity Non-operating humidity Non-operating humidity Non-operating humidity 10 to 98 % RH (non-condensing)
Mechanical Mechanical Mechanical Mechanical Buttons Buttons Buttons Buttons 11 programmable (unshifted)
Cap Force Range Cap Force Range Cap Force Range Cap Force Range 0.2 N – 4.5 N
Cap Torque Range Cap Torque Range Cap Torque Range Cap Torque Range 4 Nmm to 100 Nmm
Resolution Resolution Resolution Resolution 8 bit
USB Specifications USB Specifications USB Specifications USB Specifications Connector Connector Connector Connector USB 1.1 or greater
Cable Length Cable Length Cable Length Cable Length 6.56 ft (2 m)
Data Rate Data Rate Data Rate Data Rate 16 msec
Software Drivers Available Software Drivers Available Software Drivers Available Software Drivers Available Microsoft Windows XP Professional
System Requirements System Requirements System Requirements System Requirements Disk Space Disk Space Disk Space Disk Space 10 MB free disk space
QuickSpecs
HP xw4300 Workstation HP xw4300 Workstation HP xw4300 Workstation HP xw4300 Workstation
Technical Specifications - Input/Output Devices
