Repair Parts List
Ref. Part Numbers For Models:
No. Description 4445-95 4446-95 Qty.
1 Motor 1626-075-00 1626-076-00 1
2 Coupling 4430-143-00 4430-143-00 1
3 Column 4430-032-09 4430-032-09 1
4 Washer * * 4
5 Fastener * * 4
6 Fastener * * 3
7 Washer * * 10
8 Fastener * * 7
9 Impeller shim set (See 14)
10 Volute cover 4445-020-09 4440-020-01 1
11 Volute spacer plate 4445-060-09 4445-060-09 1
12 Fastener * * 2
13 Shaft 4445-140-00 4445-140-00 1
14 Impeller, Includes 9 & 15 4445-010-98 4445-010-98 1
15 Impeller nut 1784-001-00 1784-001-00 1
16 Gasket 4440-300-00 4440-300-00 1
17 Volute base, Includes 18 4445-001-95 4445-001-95 1
18 Debris screen (See 17) N/A N/A 1
19 N/A N/A N/A -
20 Shaft support Not available Not available 1
21 Support plate 4445-090-09 4445-090-09 1
Δ Mounting bracket kit 4420-90 4420-90 1
(Δ) Not shown.
(*) Standard hardware item, available locally.
N/A Not applicable to this model.
4 5570-250-00 03/2006
