Getting to Know Your TV 5
TV (rear)
connector
Item name Description
■ Audio Output ■ Audio
output,
analog Audio output, analog: Connect left and right audio cables for analog
stereo sound out to an optional external audio system. Use the left (white)
connector for mono sound (single cable).
■ Coaxial ■ Audio
output,
digital Coaxial audio output, digital: Connect a coaxial cable for digital
sound out to an optional external digital audio system.
■ AV1-Audio
AV1-Video
AV1-S/Video
■ AV2-Audio
AV2-Video
AV2-S/Video
■ Input 1
■ Input 2
Audiovisual in:
■ Connect a composite video cable and left-right audio cables from
optional equipment.
Or
■ Connect an S-video cable and left-right audio cables from optional
equipment.
(Audio connectors are shared.)
■ Component-1,
Component1-
Audio
■ Component-2,
Component2-
Audio
■ Input 3
■ Input 4
Component in: Connect a component video cables and left-right audio
cables from optional equipment. Supports standard inputs 480i, 480p,
720p, and 1080i. Some set-top boxes must be set for a specific
resolution out.
■ ANT ■ Ant/
Cable Antenna or cable in: Connect a coaxial cable from an air antenna or
a cable signal source as the TV input signal.
■ Audio R
Audio L ■ Input 5
Audio Audio in: Connect left and right audio cables from audio out of optional
DVI equipment that is connected using an DVI-to-HDMI adapter at HDMI
In 2 (Input 5). Use the left (white) connector for mono sound (single cable).
■ HDMI In 2
■ HDMI In 1
■ Input 5
HDMI
■ Input 6
HDMI
HDMI in: Connect an HDMI cable from optional digital, high-definition
equipment.
Use Audio R/L when using an DVI-to-HDMI adapter at Input 5 HDMI
(only).
■ AC Input ■ AC power AC power: Connect the included power cord. Note: Use only the
provided power cord.
