Page 15
BSSID
Display the MAC Address of the network the adapter is
connecting to.
Parameter Description
Signal Strength
This bar shows the signal strength level. The higher
percentage shown in the bar, the more radio signal been
received by the adapter. This indicator helps to find the proper
position of the wireless station for quality network operation.
Link Quality
This bar indicates the quality of the link. The higher the
percentage, the better the quality.
TX Frame
It shows the number of data frames which are transmitted by
the adapter successfully.
RX Frame
It shows the number of data frames which are received by the
adapter successfully.
1.5
General Connection Setting
Clicking “More Settings”, allows users to setup more advanced features, such as
wireless connection settings, Encryption Settings of the USB adapter and other
functions.
Parameter Description
15
