Important, Pole identification mark – Huffy 11S0057 User Manual
Page 9
05/04
P/N 211472
9
Bounce top and middle pole assembly and bottom pole (6) together as shown
until they no longer move toward pole identification mark.
4
5
6
3.
WOOD SCRAP
(NOT SUPPLIED)
POLE
IDENTIFICATION
MARK
POLE SECTIONS
SHOULD HAVE A
3-1/2" (9 CM) MINIMUM
OVERLAP.
NOTE:
IMPORTANT!:
Holes in top (1) and
bottom pole (3) sections
MUST align to correctly
position elevator system
toward playing surface.
