24
P/N 211472 05/04
SURE SHOT - 748
U-TURN : ADJUSTMENT
PORTABLE
201254
Eng: Dan\Tom
1st Used:
2/99
Size = 4" x 5.5"
Corner Radius = 3/8"
Die Cut Label
3.25 Mil Vinyl
All Temp. Permanent Adhesive
1 Mil. Polypropolyne Overlaminate
Illustrator 8.0 = EPS
Backing + 1/16 Circumference
Rolls of 500
Crank
Height
Indicator
Hook
201254 2/99
1
2
4
3
MOVING SYSTEM
1. Adjust basketball backboard
height to lowest position.
2. Rotate basketball system
forward, while holding pole,
until wheels engage with
ground.
3. Move basketball system to
desired location.
4. Carefully rotate basketball
system upright.
5. Reattach ground restraint and
check system for stability.
HEIGHT ADJUSTMENT
TO ADJUST BACKBOARD:
Position looped end of crank
onto hook as shown. Rotate
crank handle to raise or lower
backboard.
DIRECT MOUNT & EXT. ARM PORTABLE 201261 Eng: Dan\Tom
1st Used:
3/99
Size = 4" x 3" Corner Radius = 3/8" Die Cut Label 3.25 Mil Vinyl All Temp. Permanent Adhesive 1 Mil. Polypropolyne Overlaminate Illustrator 8.0 = EPS Backing + 1/16 Circumference Rolls of 500
201261 3/99
1 3 2
MOVING SYSTEM
1. While holding pole, rotate basketball system forward
until wheels engage with
ground.
2. Move basketball system to desired location. 3. Carefully rotate basketball system upright. 4. Reattach ground restraint and check system for stability.
SURE SHOT - 748 U-TURN : ADJUSTMENT PORTABLE 201254 Eng: Dan\Tom
1st Used:
2/99
Size = 4" x 5.5" Corner Radius = 3/8" Die Cut Label 3.25 Mil Vinyl All Temp. Permanent Adhesive 1 Mil. Polypropolyne Overlaminate Illustrator 8.0 = EPS Backing + 1/16 Circumference Rolls of 500
Crank
Height Indicator
Hook
201254 2/99
1
2
4 3
MOVING SYSTEM
1. Adjust basketball backboard height to lowest position. 2. Rotate basketball system forward, while holding pole,
until wheels engage with
ground.
3. Move basketball system to desired location. 4. Carefully rotate basketball system upright. 5. Reattach ground restraint and check system for stability.
HEIGHT ADJUSTMENT
TO ADJUST BACKBOARD:
Position looped end of crank onto hook as shown. Rotate crank handle to raise or lower backboard.
15
1.
Apply Moving Label (15) to front of pole, where it is clearly visible.
SECTION E: APPLY HEIGHT AND MOVING LABEL
