6
P/N 211472 05/04
PARTS LIST (See Hardware Identifier)
Item Qty. Part No. Description
1 1 206647 Tank (Black)
2 1 200628 Wheel Axle
3 2 226401 Wheel
4 1 908136 Top Pole Section
5 1 908077 Middle Pole Section with Label
6 1 905840 Bottom Pole Section
7 1 202820 Rod, 3/8 O.D. x 4-3/4 Long
8 1 202822 Eye Bolt, 3/8 x 16 x 3-3/4 Long
9 5 202821 Disk, 2.75 O.D.
10 9 203063 Lock Nut, Nylon Insert, 3/8-16
11 1 202622 Bolt, Hex Head, 5/16-18 x 4-1/2
12 2 906411 Tank Strut, Short
13 2 900478 Tank Strut, Long
14 1 203220 Lock Nut, 5/16-18
15 1 201254 Label, Moving System
16 2 200874 Spacer, Steel .402 I.D. x .50 O.D. x 1.5 Long
17 8 203100 Nut, Hex Flange 5/16-18
18 1 900635 Rim
19 12* 201219 Clip, Net Holder
20 1 900416 Backboard Mounting Bracket
21 18 203309 Washer, 1 O.D.
22 4 206360 Bolt, Hex 3/8-16 x 2.65 Long
23 1 206273 Bolt, Hex, 1/2-13 X 4.5" Long
24 5 201382 Support Foot
25 1 Net
26 1 207103 Pole Cap
27 6 201651 Spacer, Wheel Axle
28 1 203617 Tank Cap
29 1 908139 Plate, Jack Support, Left
30 1 908137 Plate, Jack Support, Right
31 1 204085 Decal, Height Indication
32 5 206304 Bolt, Hex 1/2-13 X 6-5/16 Long
33 6 201642 Spacer, Plastic, .63" Long
34 4 908138 Elevator Tubes
35 7 206340 Lock-Nut, Nylon Insert, 1/2-13 for bolt #32
36 1 805231 Screw Jack
37 2 206249 Bolt, Hex 1/2-13 X 1.25" Long
38 2 201129 Spacer, .5"OD x 1.8 Long
39 1 206269 Spacer, .75" O.D., 4" Long
40 1 206234 Cover, Indicator
41 1 207103 Pole Cap
42 1 806259 Crank
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
WARRANTY CARD:
Please remember to complete your product
registration form either on-line at:
www.huffysports.com/warrantycard or mail-in
the enclosed postcard.
