41
Heat & Glo • Supreme-XTS, Grand-XTS • 349-901 Rev. G • 9/08
Service Parts
Service Parts Diagram
GRAND-XTS
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Set Assembly LOGS-GXT Y
1 Log 1 SRV339-701
2 Log 2 SRV339-702
3 Log 3 SRV327-703
4 Log 4 SRV339-704
5 Log 5 SRV438-724
6 Log 6 SRV327-705
7 Log 7 SRV571-707
8 Fireplace Termination Assembly 319-213A
9 Burner 339-176A Y
10 Grate Assembly 339-360A
11 Base Pan 339-124
12 Control Panel 319-129
13 Flame Control Knob 571-533 Y
14 Piezo Ignitor 291-513 Y
15 Glass Door Assembly GLA-339 Y
16 Pilot Control Knob 571-534 Y
17 Rheostat Knob 100-512 Y
18 On/Off Rheostat 319-510A Y
19 Junction Box 040-250A Y
20 Blower GFK-160A
Flex Pipe Handle 438-351
Glass Latch Assembly 386-122A Y
Mineral Wool 050-721
Orifi ce NG (#32C) 582-832 Y
Orifi ce LP (#51C) 582-851 Y
Pilot Tube SRV485-301 Y
Thermocouple 2103-511 Y
Thermopile 2103-512 Y
Touch Up Paint 203-9
Conversion Kit NG NGKS-GXT Y
Conversion Kit LP LPKS-GXT Y
Pilot Orifi ce NG 2103-116 Y
Pilot Orifi ce LP 2103-117 Y
Regulator NG 230-1570 Y
Regulator LP 230-1520 Y
Additional service part numbers appear on following page.
