Page 39
39
Heat & Glo • Supreme-XTS, Grand-XTS • 349-901 Rev. G • 9/08
Service Parts Diagram
SUPREME-XTS
Service Parts
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM
DESCRIPTION
COMMENTS
PART NUMBER
Log Set Assembly
LOGS-SXT
Y
1
Log 1
SRV349-701
2
Log 2
SRV349-702
3
Log 3
SRV327-703
4
Log 4
SRV349-704
5
Log 5
SRV327-705
6
Log 6
SRV349-706
7
Fireplace Termination Assembly
319-213A
8
Burner
349-176A
Y
9
Grate Assemby
327-360A
10
Base Refractory
349-124
11
Control Panel
319-129
12
Piezo Ignitor
291-513
Y
13
Flame Control Knob
571-533
Y
14
Glass Door Assembly
GLA-349
Y
15
Pilot Control Knob
571-534
Y
16
Rheostat Knob
100-512
Y
17
On/Off Rheostat
319-510A
Y
18
Junction Box
040-250A
Y
19
Blower
GFK-160A
Flex Pipe Handle
438-351
Glass Latch Assembly
386-122A
Y
Mineral Wool
050-721
Orifi ce NG (#35C)
582-835
Y
Orifi ce LP (#52C)
582-852
Y
Pilot Tube
SRV485-301
Y
Thermocouple
2103-511
Y
Thermopile
2103-512
Y
Touch Up Paint
203-9
Conversion Kit NG
NGKS-SXT
Y
Conversion Kit LP
LPKS-SXT
Y
Pilot Orifi ce NG
2103-116
Y
Pilot Orifi ce LP
2103-117
Y
Regulator NG
230-1570
Y
Regulator LP
230-1520
Y
Additional service part numbers appear on following page.
