Dispenser precautions
Door removal
Precautions
The following instructions refer only to products equipped with an ice cube maker, ice
crusher and refrigerated water dispenser.
● Do not use very tall or short glasses.
● Hold the glass as close as possible to the ice cube outlet so as to prevent dropping
ice cubes or jamming the ice cube supply.
● The outlet closes five seconds after ice cubes have been supplied.
● When helping yourself to ice cubes, hold the glass under the outlet for 2 to 3
seconds after releasing the switch, as more ice cubes may be delivered.
When helping yourself to water, hold the glass under the outlet for 10 to 20 seconds
after releasing the switch, as more water may be delivered.
● Regularly empty the water collection tray and wipe off water drops from the
dispenser using a rag.
● When selecting ice cubes after crushed ice was last dispensed, a few remaining
pieces of crushed ice may be delivered.
● Remove any remaining ice shavings from the outlet to prevent jamming.
● Do not place drinks or other foods in the ice cube container, as this may
damage the ice maker.
● To avoid injuries, do not touch the ice outlet with your hand and do not remove the
ice maker cover.
● Do not consume the first seven or so glasses of water and 20 or so ice cubes after
starting up the appliance for the first time or following a long period of inoperation.
● Do not place ice cubes other than the ones produced by the appliance in the ice cube
container, as they may not be properly delivered or crushed.
● An insufficient water supply line may cause ice cubes to be too small. An excessive
water supply line may cause ice cubes to be too large. Moreover, water may
overflow into the ice cube container, causing the ice cubes to stick together. Adjust
the faucet accordingly or contact an authorised professional.
Slide the refrigerator through the door opening.
Slide the refrigerator through the door
opening as shown in the illustration.
Reinstall the door.
Bring the doors in the house, and then reinstall them by
reversing the removal steps.
Remove the refrigerator compartment
door.
1) Loosen the hinge cover bolts, and then
remove the cover. Disconnect any wires
except for the grounding wire.
2) Remove the screws from the upper hinge
following the direction as indicated by Arrow
(1). Then remove the upper hinge following
the direction as indicated by Arrow (2).
2) Lift the refrigerator compartment
door to remove it.
screw
Lower hinge
Caution: The valve and relay may produce audible sounds while ice cubes
are being supplied
Wires
Upper hinge
