47
C. Service Parts
5/08
Service Parts Service Parts Diagram 42 in. See-through W
oodburning Fireplace
Part number list on following page.
HST
-48D
2
1
8
6
91
0
11
7 5
12
4
3
Duct sold separately
13
14
15
Side of Fireplace
Beginning Manufacturing Date:
Aug 2001
Ending Manufacturing Date:
Active
5/08
Service Parts Service Parts List 42 in. See-through W
o
odburning Fireplace
HST
-48D
IMPOR
TANT
: THIS IS DA
TED INFORMA
TION. When requesting service or replacement
parts for your appliance please provide model number and serial number
. All parts listed
in this manual may be ordered from an authorized dealer
.
Stocked at Depot
ITEM
D
ESCRIPTION
COMMENTS
P
A
RT NUMBER
1
Damper Blade
Assembly
34487
N
Damper W
eight
19785A
N
2
S
tarter Section
Assembly
22072B
Y
3
Top Standof
fs
Qty
. 4 req.
4044-1
11
N
4
S
moke Shield
Qty
. 2 req.
16829F
N
5
S
ide Refractory
Qty
. 2 req.
27069
N
6
Corner Refractory
Qty
. 4 req.
27070
N
7
F
irescreen Assembly
Qty
. 4 req.
27508
Y
Firescreen Handle
1 ea.
4021-149
N
8
Door Support
Qty
. 2 req.
16697D
N
9
Ashlip
Qty
. 2 req.
16674B
N
10
Hearth Refractory
16673A
N
11
G
ra
te
GR1
1
Y
12
Damper Control
16663
N
13
Air Kit
AK17
N
14
Outside Air
Plate Assembly
19081A
N
15
Outside Air
Shield
33271
Y
AK17 Installation Instructions
31
168
N
Air Kit Fastener Pack
17916B
N
Bottom Door
T
rack
(used for upper)
Qty
. 2 req.
4012-001
N
Door Pivot Clip
Qty
. 2 req.
31527
N
Door T
rack
(used for lower)
Qty
. 2 req.
15427
N
Exterior T
ouch-Up
Paint
71479
N
Firescreen Rod
Qty
. 4 req.
11
755A
N
Gas
Access Panel (for use with
Air Kit)
31636
N
Grate Retainer
Qty
. 2 req.
17365D
N
Nailing Flange
Qty
. 8 req.
31
190
N
Refractory Bracket
Qty
. 4 req.
23959A
N
Refractory Retainer
Qty
. 4 req.
16675B
N
Refractory Retainer
Qty
. 4 req.
11
847
N
Refractory Standof
f
Qty
. 6 req.
16678
N
Smoke Shelf
Qty
. 2 req.
16676B
N
Smoke Shield Kit
S
R
V
4012-036
N
Fastener Pack
12010B
N
Smoke Shield Kit Installation Instructions
4017-075
N
Strip Protector
Qty
. 4 req.
18320
N
Installation Instructions & Owner's Manual
35039
N
Beginning Manufacturing Date:
Aug 2001
Ending Manufacturing Date:
Active
Heat & Glo • HST-48D US-CAN • 4012-040 • Rev F • 11/08
