Adjusting the Butterfly Arms
Make sure the Backrest (12) is in the horizontal position
as described on the previous page. Pull out the
Adjustment Knob (66) on one of the Adjustment Discs
(26, 27) and pivot the Butterfly Arm (10 or 11) up or down
to the desired position. Release the Adjustment Knob and
let it snap into one of the adjustment holes in the Disc.
Note: The Adjustment Discs (26, 27) each have three
adjustment holes for use during regular exercises.
Each Disc also has one hole for use when the
Butterfly Arms are stored in a vertical position, point-
ing towards the floor.
27
26
66
11
12
10
Press Lower
Upper
Butterfly
Leg
Weight
Arm
Pulley Pulley
(one
side)
Lever
Plates
(lbs.)
(lbs.)
(lbs.)
(lbs.)
(lbs.)
TopÑ1
15
18
16
9
15
2
24
31
26
15
27
3
35
40
38
19
37
4
46
54
49
25
49
5
56
64
57
28
59
6
67
76
69
32
71
7
77
87
80
37
84
8
87
99
94
43
94
9
99
110
104
50
107
10
110
122
116
56
114
11
119
133
128
63
128
12
129
145
142
65
139
13
139
159
151
72
149
14
150
172
164
80
162
15
163
183
174
81
173
*16
169
199
183
87
154
*17
182
213
196
93
198
*18
194
223
209
97
206
*19
202
228
219
102
220
*20
211
240
229
109
234
The chart below shows the approximate weight resistance at each exercise station. ÒTopÓ refers to the 10 lb. top
weight; the other numbers refer to the 10 lb. weight plates. Note: The actual resistance at each station may
vary due to differences in individual weight plates as well as friction between the cables, pulleys, and
weight guides. This chart shows the resistance for the five extra weight plates included with the Weight
Expansion Set (see No. 16-20 below). The set is available as a separate purchase; ask for Model No.
HRSA15080.
Weight Resistance Chart
