Healthrider HRSY23080 - Manual (Page 15)

15
36. Route the High Cable (73) through the slot in the leg
of the Seat Frame (7).
Attach the closed loop at the end of the High Cable
(73) to the Leg Lever (41) with a 3/8Ó x 2 3/4Ó Bolt
(47), two 3/8Ó Flat Washers (55) and a 3/8Ó Nylon
Locknut (50). Note: Do not overtighten the Nylon
Locknut.
36
41
7
55
55
50
47
73
Slot
37. Identify the Butterfly Cable (92). It is approximate-
ly 61Ó long and it has a loop on both ends.
Attach one end of the Butterfly Cable (92) to the Left
Adjustment Disc (26) with a 5/16Ó x 1Ó Bolt (87), a
3/8Ó Flat Washer (55), a 1/2Ó x 3/8Ó Bushing (83) and
a 5/16Ó Nylon Locknut (64). Note: The loop on the
Cable must wrap around the 1/2Ó x 3/8Ó Bushing.
For the sake of clarity, some parts have been
removed and the Adjustment Disc is shown
exploded.
37
83
64
55
87
26 92
38. Wrap the Butterfly Cable (92) around a 3 1/2Ó Pulley
(24) in the direction shown.
Attach the 3 1/2Ó Pulley (24) and a Cable Trap (25) to
the lower half of the Adjustable Pulley Frame (23)
with a 3/8Ó x 2Ó Bolt (54) and a 3/8Ó Nylon Locknut
(50). The Pulley must be attached to the middle of
the three adjustment holes.
Note: For the sake of clarity, some parts have
been removed from the drawing.
38
50
54
25
23
24
92
39. Attach the free end of the Butterfly Cable (92) to the
Right Adjustment Disc (27) with a 5/16Ó x 1Ó Bolt (87),
a 3/8Ó Flat Washer (55), a 1/2Ó x 3/8Ó Bushing (83)
and a 5/16Ó Nylon Locknut (64).
Note: The loop on the Cable must wrap around
the 1/2Ó x 3/8Ó Bushing.
39
92
83
64
27
55
87
