Horizon Fitness ASCENT TRAINER AT1501 - Manual (Page 7)

BEFORE
YOU BEGIN
12
INTRODUCTION
IMPORT
ANT
PRECAUTIONS
ASSEMBL
Y
BEFORE
YOU
BEGIN
ASCENT
TRAINER
OPERA
TION
LIMITED
W
ARRANTY
TROUBLESHOOTING
&
MAINTENANCE
CONDITIONING
GUIDELINES
BEFORE YOU
BEGIN
ASSEMBL
Y
1
INTRODUCTION
IMPORT
ANT
PRECAUTIONS
ASCENT
TRAINER
OPERA
TION
CONDITIONING GUIDELINES
TROUBLESHOOTING &
MAINTENANCE
LIMITED WARRANTY
BOLTS (K)
WASHERS (L)
LINK ARM
FOOTPAD
WASHER (L)
18 mm
Qty: 8
BOLT (K)
12 mm
Qty: 8
WASHER (M)
18 mm
Qty: 8 BOLT (J)
12 mm
Qty: 8
HARDWARE BAG CONTENTS:
ASSEMBLY STEP :
Open HARDWARE BAG 6.
Attach FOOTPAD to the footpad support on the right LINK ARM using 4 BOLTS (K) and 4 WASHERS (L).
Repeat with the left LINK ARM.
A
B
C
ASSEMBLY STEP
BOLT (C)
WASHER (K)
WAVY WASHER (M)
SWING ARM
PEDAL ARM
LINK ARM
BOLT (C)
16 mm
Qty: 2
WASHER (K)
38 mm
Qty: 2
WAVY WASHER (M)
34 mm
Qty: 2
HARDWARE BAG CONTENTS:
ASSEMBLY STEP :
Open HARDWARE BAG 7.
Attach right LINK ARM to right PEDAL ARM using 1 BOLT (C), 1 WASHER (K) and 1 WAVY WASHER (M).
Repeat on opposite side.
Discard packaging plastic.
A
B
C
D
ASSEMBLY STEP
