HP ProLiant ML370 G5 Model (Rack) HP ProLiant ML370 G5 Model (Rack) HP ProLiant ML370 G5 Model (Rack) HP ProLiant ML370 G5 Model (Rack)
Front View: Front View: Front View: Front View: Rear View: Rear View: Rear View: Rear View:
1. System Insight Display (SID) 1. Keyboard connector
2. Video Connector 2. Mouse connector
3. DVD/CD-ROM Drive 3. USB connectors
4. Removable Media Bays 4. Integrated Lights-Out 2 (iLO 2) management connector
5. Hard Drive Bays 1-8 (Serial-attached SCSI (SAS) drives
supported - SFF) 5. Video connector
6. Serial connector
6. Hard Drive Bays 9-16 - Optional Drive Cage (Serial-
attached SCSI (SAS) drives supported - SFF) 7. NIC 2 connector
8. PCI expansion slots
7. Rack Handles 9. Hot-plug power supply (primary bay)
10. Hot-plug power supply blank (redundant bay)
11. NIC 1 connector
12. T-15 Torx screwdriver
What's New What's New What's New What's New
Dual-core Intel® Xeon® Processor 5200 Series Low Voltage processor
At A Glance At A Glance At A Glance At A Glance
The flagship ML370 G5 provides industry-leading management, performance and availability in a dual processor expansion server
engineered to excel in a variety of environments - from corporate work groups in growing businesses to critical remote sites requiring
continuous accessibility and uptime.
Processors: Processors: Processors: Processors:
Quad-core Intel® Xeon® 5400 sequence processors with 12MB Level 2 cache (6MB per die) for blazing performance
Quad-core Intel® Xeon® 5300 sequence processors with 8MB Level 2 cache (2MB per core)
Dual-core Intel® Xeon 5200 sequence processors with 6 MB Level 2 cache (3MB per core)
QuickSpecs
HP ProLiant ML370 Generation 5 (G5) HP ProLiant ML370 Generation 5 (G5) HP ProLiant ML370 Generation 5 (G5) HP ProLiant ML370 Generation 5 (G5)
Overview
DA - 12478 Canada — Version 33 — May 14, 2008 Page 2
