91
APPENDIX
Component Video Signal Format
If PDP cannot reproduce proper video image, it's necessary to select a specific component video signal format among the
below.
- DVD : 480i / 480p / 720p / 1080i
- DTV (Digital Broadcast) : 480p / 720p / 1080i
- All signals are available for 60Hz.
PDP couldn't display proper video image in case of different output signal from the specifiation that PDP supports.
(The below specification table) Then, please adjust the output signal setting from the appliances.
Or when you would like to purchase PDP & the appliances like SETTOP BOX or DVD, please check the compatibility
between the input signal of PDP and the output signal of the appliances.
• Component Input Specification
Horizontal Frequency (KHz) Vertical Frequency (KHz) Signal Name
15.75
15.734
15.75
15.734
15.75
15.734
31.5
31.469
31.5
31.469
31.5
31.469
45
44.955
33.75
33.716
60
59.94
60
59.94
60
59.94
60
59.94
60
59.94
60
59.94
60
59.94
60
59.94
DVD input
DVD input
DTV Input
Remarks
480 60i
480 60i
480 60i
480 60p
480 60p
480 60p
720 60p
1080 60i
720 x 483
720 x 486
640 x 480
720 x 483
720 x 486
640 x 480
1280 x 720
1920 x 1080
