38
SERVICING YOUR TILLER
HONDA F220 (E) 00X31-V14-6120 -
SPARK ARRESTER SERVICE (optional equipment)
Your engine is not factory-equipped with a spark arrester. In some areas, it
is illegal to operate an engine without a spark arrester. Check local laws and
regulations. A spark arrester is available from Honda servicing dealers.
The spark arrester must be serviced every 100 hours to keep it functioning
as designed.
If the engine has been running, the muffler will be very hot. Allow the muffler
to cool before servicing the spark arrester.
1. Remove the three 5 mm bolts from the muffler protector, and remove the
muffler protector.
2. Remove the special screw from the spark arrester, and remove the spark
arrester from the muffler.
3. Use a brush to remove carbon deposits
from the spark arrester screen. Be
careful to avoid damaging the screen.
The spark arrester must be free of
breaks and holes. Replace the spark
arrester if it is damaged.
4. Install the spark arrester and muffler
protector, in the reverse order of
disassembly.
MUFFLER PROTECTOR
SPECIAL SCREW
SPARK ARRESTER 5 mm BOLTS
