CONTROLS
COMPONENT & CONTROL LOCATIONS
THROTTLE LEVER
ENGINE SWITCH
FUEL TANK CAP
ENGINE OIL
FILLER CAP
FRONT
WHEEL
TRANSMISSION OIL
FILLER CAP
HANDLEBAR HEIGHT
ADJUSTER
AIR CLEANER
ENGINE OIL
DRAIN BOLT
STARTER GRIP
CHOKE LEVER
CLUTCH LEVER
FUEL VALVE
DRAG BAR
TRANSMISSION OIL LEVEL
CHECK BOLT
TINE BLADES
MUFFLER
SPARK PLUG CAP
