30
SERVICING YOUR TILLER
HONDA F220 (E) 00X31-V14-6120 -
TRANSMISSION OIL LEVEL CHECK
Check the transmission oil level with the tiller on a level surface and the
engine stopped.
1. Remove the transmission oil level check bolt. The oil should be level with
the lower edge of the oil filler hole.
TRANSMISSION
OIL LEVEL CHECK BOLT
UPPER LIMIT
(Lower edge of
the oil filter hole.)
F220_EN.book 30 ページ ２０１０年２月１２日 金曜日 午前１１時２分
