27

SERVICING YOUR TILLER

HONDA F220 (E) 00X31-V14-6120 -

ENGINE OIL LEVEL CHECK

Check the engine oil level with the tiller on a level surface and the engine
stopped.

1. Remove the oil filler cap. Check that the oil level is at the upper limit of the

oil level gauge.

2. If the oil level is low, fill to the upper limit of the level gauge with the

recommended oil (see page 29).

3. Screw in the oil filler cap securely.

OIL FILLER CAP

OIL LEVEL GAUGE

LOWER LIMIT

FRONT SIDE

UPPER LIMIT

AIR CLEANER
SIDE
