Hayter Mowers Clipper 46 401R User Manual
Page 42
401R TRANSMISSION PARTS LIST
401001EB100398A
2.4
2.4
PARTS LIST
TEM NO.
DESCRIPTION PART NO. QTY
1
Wheel mounting-R.H.
ST1111290001
1
2
Wheel mounting-L.H.
ST1111290101
1
3
*Bronze bearing
ST9548001400
2
4
*Plastic knob
ST1111254901
1
5
Spacer
ST1111306501
2
6
Cover plate
ST1111256101
2
7
Pin
ST1111238201
2
8
Gear wheel
ST1111263502
2
9
Washer
ST9699010002
2
10
Screw
ST9943061216
2
16
Washer
ST9699003702
2
17
Spring
ST1111113801
2
18
Wheel assy
ST1111266501
2
19
*Ball bearing kit
ST1111904701
1
20
*Bearing cone
ST1111118401
2
21
Washer
ST9699010002
2
22
Screw
ST9943061216
2
23
Hub cap-black
ST1111308506
2
30
Front cover-black
ST1111263302
1
31
Screw
ST9943053016
1
32
Screw
ST9943054016
2
33
Nut
ST9739053122
2
40
V-belt
ST1111906201
1
41
Engine belt pulley
ST1111291501
1
42
Set screw
ST9910061216
1
45
Transmission assy
ST1111305501
1
46
*Belt pulley dito
ST1111304701
1
47
*Locating pin
ST9594005500
1
49
Spring
ST1111306001
1
65
Clutch control
ST1111296503
1
66
Lock nut
ST9747063102
2
67
Screw
ST9948065516
2
68
Screw
ST9836951212
1
75
Cable holder
ST1111201801
1
76
Screw
ST9836921612
1
77
Cable holder
ST9579000800
1
78
Control knob-black
ST1111198702
1
79
Decal - Hayter
533005
1
*These components form part of a sub-assembly.
The quantities indicated are per sub-assembly
