Maintenance – Hayter Mowers Clipper 46 401R User Manual
Page 25
WARNING: PREVENT ACCIDENTS - Stop the engine
and disconnect the spark plug lead before attempting to
carry out maintenance procedures on the mower.
MAINTENANCE
401001EB100398A
1.24
1.24
MAINTENANCE
ENGINE
3
2
1
6
5
4
11
10
9
8
7
12
1. Governor control lever
2. Air cleaner
3. Start-grip
4. Finger Guard
5. Muffler
6. Spark plug
7. Primer bulb
8. Carburettor
9. Fuel Cap
10.Fuel tank
11.Flywheel
12.Oil fill/Dipstick
CS044
STOP
CS044
STOP
